42
Pilot alignment metal
If this metal is attached on the
decoupled motor, put it back to
the pilot on the actuator side.
Kyodo Yushi’s Multemp LRL3 has been
applied before shipment.
5) Remove the motor.
•
Remove the affixing bolts (M3 × 50, 2 pcs.) using
an Allen wrench of 2.5mm across flats.
• Pull out the motor by hand.
• Decoupled motor
6) Apply grease to the coupling on the actuator side.
Note: Never use any fluorine-based grease.
It will chemically react with
lithium-based
