47
Pilot alignment metal
If this metal is attached on the decoupled
motor, put it back to the pilot on the
actuator side.
Kyodo Yushi’s Multemp LRL3 has been
applied before shipment.
5) Remove the motor.
•
Remove the affixing bolts (M4 × 15, 4 pcs.) using an Allen wrench of 3mm across flats.
• Decoupled motor
6) Apply grease to the coupling on the actuator side.
Note: Never use any fluorine-based grease. It
will chemically react with lithium-based
To Next Page
