Module LED LED behavior states
HS Expander Status
LED:
Expander OK (Off) Expander fault ID
(Amber/blinking amber)
Power off (Off)
The replacement procedure should be completed within an absolute maximum of 3 minutes.
Enclosure management
IOMs/EBOD expander modules actively manage the enclosure. Each module has a SAS expander with its
own storage enclosure processor (SEP) that provides a SES target for a host to interface through the ANSI
SES Standard. If one of these modules fails, the other module will continue to operate.
Refer to a module’s specication or the SES Interface specication for denitions of the module’s
functions and its SES control.
The storage system also provides a command-line Interface (CLI).
Command-line interface
The command line interface can be accessed in the following ways:
• Serial port connection
• Ethernet Telnet connection
• Ethernet WBCLI utility
• SESCLI utility
Chapter 3. System Overview
25
