Field-replaceable units
FRUs addressing Model 106-drive chassis
Table 11. Model 106 product FRU components for Model 106-drive chassis
Item Enclosure component description
1 Chassis (sheet metal enclosure) with integrated PCBAs (included with chassis;
not available separately)
2 Rail kit (variable attachment options)
a) Rack mount kit, shelf, long(1.2 m), HW
b) Cable Management Arm (CMA) and brackets
Table 12. Part numbers of Field replaceable units
Part # Part Desc Substitute Part
001LU187 Kit, Slide Rails
001YK763 Kit, Slide Rails 001LU187
001YK729 Kit, Slide Rails 001YK763
001LU186 FRU Chassis
001YK761 FRU Chassis
001NN741 FRU Chassis 001YK761
002AE940 FRU CMA
001YK767 FRU CMA 002AE940
001NN746 FRU CMA 001YK767
001NN748 FRU FAN T-2
002AE987 PSU 2KW
FRU Assembly FRU PSU URL
002AE983 PSU 2KW
FRU PSU HAL
001NN747 FRU SAS Expander
001YK792 CRU TOP LID 4U
Chapter 6. Troubleshooting and problem solving 65
