Table 10. Part numbers of Customer-replaceable units (continued)
Part # Part Desc Substitute Part
001LU643 800GB 2.5 SSD
001LU641 8TB 3.5 HDD
001LU160 FRU: Bezel Ears
001NN743 Power Cable, 3M, C19/C20
001NN744 Power Cable, 4M, C19/C20
001NN740 EBOD (Expander) Asm
001ML987 Serial Cable Asm
001NN739 FRU FAN T-1
001LU138 Kit, Lift Handles
001NN745 MiniSAS Cable, 5m (Copper)
001LU136 MiniSAS Cable, 4m (Copper)
001NN738 FRU PSU 2KW 002AE983
001NN749 Power Cable, 2.5, C19/C20
078P6721 5.5M Cable (Optical SAS)
002YC507 16TB 3.5 HDD
001LU177 LABELS (DRIVE NUMBERING)
001LU172 Foam/Clamps Kit for Cables
001LU167 Foam/Clamps Kit for Cables 001LU172
1. The Access column lists the enclosure panel from which the CRU is observed and accessed. It does
not apply to other components.
2. See “Enclosure chassis” on page 14 for a description of the chassis CRU.
3. See “Rackmount rail kit” on page 32 and “Routing cables using the CMA” on page 45 for descriptions
of the rail kit and CMA.
Tip: Enclosure panel access diagrams for locating CRUs:
• Front panel: see Figure 3 on page 9 and Figure 12 on page 15
• Rear panel: see Figure 4 on page 10
• Top panel: see Figure 9 on page 12, Figure 10 on page 13, and Figure 11 on page 13
Tip: Enclosure dimetric pictorial views:
• Projection from enclosure front panel: see Figure 1 on page 7
• Projection from enclosure rear panel: see Figure 2 on page 8
64
IBM ESS expansion: Hardware Installation and Maintenance Guide - Model 106
