Table 35. Cabling a Four Node Conguration
Cable Cable type and length From To
Cables originating on ND4
2C 1225 mm (4.01
ft)
ND4-P1-T1 ND2-P1-T3
2D 1225 mm (4.01
ft)
ND4-P1-T2 ND2-P1-T4
4C 880 mm (2.9
ft)
ND4-P1-T3 ND3-P1-T3
4D 880 mm (2.9
ft)
ND4-P1-T4 ND3-P1-T4
1C 1425 mm (4.7
ft)
ND4-P1-T7 ND1-P1-T3
1D 1425 mm (4.7
ft)
ND4-P1-T8 ND1-P1-T4
2A 1225 mm (4.01
ft)
ND4-P1-T9 ND2-P1-T11
2B 1225 mm (4.01
ft)
ND4-P1-T10 ND2-P1-T12
4A 1005 mm (3.3
ft)
ND4-P1-T11 ND3-P1-T11
4B 1005 mm (3.3
ft)
ND4-P1-T12 ND3-P1-T12
1A 1625 mm (5.3
ft)
ND4-P1-T15 ND1-P1-T11
1B 1625 mm (5.3
ft)
ND4-P1-T16 ND1-P1-T12
1W 1625 mm (5.3
ft)
ND4-P1-T17 ND1-P1-T21
1X 1625 mm (5.3
ft)
ND4-P1-T18 ND1-P1-T22
4W 1005 mm (3.3
ft)
ND4-P1-T21 ND3-P1-T21
4X 1005 mm (3.3
ft)
ND4-P1-T22 ND3-P1-T22
2W 1225 mm (4.01
ft)
ND4-P1-T23 ND2-P1-T21
