Table 3. Cabling a Three Node Conguration (continued)
Cable Cable type and length From To
6A 1225 mm (4.01
ft)
ND2-P1-T15 ND1-P1-T15
6B 1225 mm (4.01
ft)
ND2-P1-T16 ND1-P1-T16
6W 1225 mm (4.01
ft)
ND2-P1-T17 ND1-P1-T17
6X 1225 mm (4.01
ft)
ND2-P1-T18 ND1-P1-T18
6Y 1005 mm (3.3
ft)
ND2-P1-T25 ND1-P1-T25
6Z 1005 mm (3.3
ft)
ND2-P1-T26 ND1-P1-T26
• If you have a four node system conguration, use Figure 29 on page 34 and Table 4 on page 35
to determine the point-to-point cabling for SMP cables.
