IBM 9080-M9S

Figure 397. Installing an adapter in a cassette for the 9080-M9S system
11. Replace the top cover on the cassette.
a) Lower the top cover on the top of the cassette.
b) Slide the top cover in the direction that is shown in the following gure until it latches securely.
460
Power Systems: Removing and replacing parts in the 9080-M9S system
