Figure 474. Cabling a Three Node Conîš³guration
Table 56. Cabling a Three Node
Conîš³guration
Cable Cable type and length From To
5C 880 mm (2.9
ft)
ND3-P1-T1 ND2-P1-T1
544 Power Systems: Removing and replacing parts in the 9080-M9S system
