Figure 477. Attaching a cable clip
To determine how to bundle the cables and where to attach the cable bundles, refer to the
information card inserted into the rear of the system control unit. You can also refer to the
following gures. The number in the cable label indicates the bundle for that cable.
Two system node conguration: The two system node conguration has four cable bundles.
552
