IBM 9080-M9S

Figure 538. Installing the system processor module
e) Open the latches that hold the system processor module in the supplied removal tool (A) as
shown in the following gure. Push down on the ring (B) while pressing in on the tabs (C).
616
Power Systems: Removing and replacing parts in the 9080-M9S system
