If you have another device such as a tape unit or a CD-ROM drive,
refer to the instructions that came with that device.
__ 19. Install the front cover on the expansion unit.
DANGER
An electrical outlet that is not correctly wired could place hazardous voltage
on metal parts of the system or the products that attach to the system. It is the
customer’s responsibility to ensure that the outlet is correctly wired and
grounded to prevent an electrical shock. (RSFTD201)
__ 20. Plug the following power cords into an electrical outlet.
v Expansion unit
v System-unit console
__ 21. Plug in and power on all attached devices, such as printers and displays.
__ 22. Look at the Function/Data display on the system-unit control panel. Does
a B appear in the Function/Data display?
Yes No
↓ Do the following:
a. Press the Up or Down select push button until 02 appears in
the Function/Data display.
b. Press the Enter push button on the control panel.
c. Press the Up or Down select push button until B appears in the
Function/Data display.
d. Press the Enter push button on the control panel.
e. Press the Up or Down select push button until 01 appears in
the Function/Data display.
f. Press the Enter push button on the control panel.
g. Is the IPL mode Normal?
Yes No
↓ Press the mode button until a lit mode light indicates
that the action mode is Normal. Go to step 24.
h. Go to step 24.
__ 23. Make sure that the IPL mode is in Normal mode. If it is not, press the
mode button until a lit mode light indicates that the action mode is
Normal.
__ 24. Power on the workstation or PC that is console for your system.
__ 25. Press the power button to power on your AS/400 system unit.
__ 26. Sign on the AS/400 system-unit. Ensure that you have service tools
authority.
__ 27. Do the following to verify your removable media device configuration:
Appendix D. Installing removable media devices in the 5065 Expansion Unit 63
