4.3 Models
In addition to the details in the tables in this chapter, each standard model has the following
specifications:
The servers have 16 DIMM sockets on the system planar. The additional 16-DIMM socket
memory mezzanine (memory tray) is optional on most models and must be ordered
separately. See 4.8, “Memory” on page 131 for details.
The MAX5 is optional on certain models and standard on others.
The optical drive is not standard and must be ordered separately if an optical drive is
required. See 4.9.8, “Optical drives” on page 163 for details.
As noted in the tables, most models have drive bays standard (
std). However, disk drives
are not standard and must be ordered separately. In the tables,
max indicates maximum.
Base x3690 X5 models
Table 4-1 provides the standard models of the x3690 X5. The MAX5 memory expansion unit
is standard on specific models, as indicated.
Table 4-1 x3690 X5 models
Model
Intel Xeon
processors
(two maximum)
Memory
speed MAX5
Standard
memory
a
a. Up to 64 DIMM sockets: Each server has 16 DIMM sockets standard or 32 sockets with the addition of the internal
memory tray (mezzanine). With the addition of the MAX5 memory expansion unit, 64 DIMM sockets total are
available.
Memory tray
ServeRAID
M1015 standard
10Gb Ethernet
standard
b
b. Emulex 10Gb Ethernet Adapter
Power
supplies
std/max
Drive
bays
std/max
7148-ARx
1x E7520 4C,
1.86 GHz, 95W
800 MHz Opt Server: 2x 4GB Opt Opt Opt 1/4 None
7148-1Rx
1x E7520 4C,
1.86 GHz, 95W
800 MHz Opt Server: 2x 4GB Opt
Std Opt 1/4 4x 2.5”/16
7148-2Rx
1x E6540 6C,
2.00 GHz, 105W
1066 MHz Opt Server: 2x 4GB Opt
Std Opt 1/4 4x 2.5”/16
7148-3Rx
1x X6550 8C,
2.00 GHz, 130W
1066 MHz Opt Server: 2x 4GB Opt
Std Opt 1/4 4x 2.5”/16
7148-3Gx
1x X6550 8C,
2.00 GHz, 130W
1066 MHz Opt Server: 2x 4GB Opt
Std Std 1/4 4x 2.5”/16
7148-4Rx
1x X7560 8C,
2.26 GHz, 130W
1066 MHz Opt Server: 2x 4GB Opt
Std Opt 1/4 4x 2.5”/16
7148-3Sx
1x X7550 8C,
2.00GHz, 130W
1066 MHz
Std
Server: 2x 4GB
MAX5: 2x 4GB
Opt
Std Opt
Server: 2/4
MAX5: 1/2
4x 2.5”/16
7148-4Sx
1x X7560 8C,
2.26GHz, 130W
1066 MHz
Std
Server: 2x 4GB
MAX5: 2x 4GB
Opt
Std Opt
Server: 2/4
MAX5: 1/2
4x 2.5”/16
