168 IBM eX5 Implementation Guide
SFP+ transceivers are not included with the server and must be ordered separately.
Table 4-34 lists compatible transceivers.
Table 4-34 Transceiver ordering information
4.10.4 I/O adapters
Table 4-35 on page 168 shows the current list in the Configuration and Options Guide (COG)
at the time of writing this paper. See the following website:
http://www.ibm.com/systems/info/x86servers/serverproven/compat/us/
Table 4-35 Available I/O adapters for the x3690 X5
Option number Feature code Description
49Y4218 0064 QLogic 10Gb SFP+ SR Optical Transceiver
49Y4216 0069 Brocade 10Gb SFP+ SR Optical Transceiver
46C3447 5053 BNT SFP+ Transceiver
Option Feature code Description
Networking
59Y1887 5763 QLogic QLE7340 single-port 4X QDR IB x8 PCI-E 2.0 HCA
39Y6071 1485 NetXtreme II 1000 Express G Ethernet Adapter- PCIe
49Y4253 5749 Emulex 10GbE Virtual Fabric Adapter
49Y4243 5768 Intel Ethernet Quad Port Server Adapter I340-T4
49Y4233 5767 Intel Ethernet Dual Port Server Adapter I340-T2
49Y4223 5766 NetXtreme II 1000 Express Quad Port Ethernet Adapter
49Y4200 1648 Emulex 10Gb Dual-port Ethernet Adapter
42C1823 1637 Brocade 10Gb CNA
42C1803 5751 QLogic 10Gb CNA
42C1793 5451 NetXtreme II 10 GigE Express Fiber
42C1783 2995 NetXtreme II 1000 Express Dual Port Ethernet Adapter
42C1753 2975 PRO/1000 PF Server Adapter
39Y6139 2974 PRO/1000 PT Quad Port Server Adapter
39Y6129 2944 PRO/1000 PT Dual Port Server Adapter
Storage
42D0486 3580 Emulex 8Gb FC Single-port HBA
42D0495 3581 Emulex 8Gb FC Dual-port HBA
42D0502 3578 QLogic 8Gb FC Single-port HBA
42D0511 3579 QLogic 8Gb FC Dual-port HBA
46M6051 3589 Brocade 8Gb FC Single-port HBA
