Table 11. Mapping network adapter ports to IBM Flex System Enterprise Chassis I/O bays for the IBM Flex System
p260 Compute Node (continued)
Port location
code
IBM Flex
System 2-port
QDR
InfiniBand
adapter
IBM Flex
System 2-port
10 Gb RoCE
adapter
IBM Flex
System 2-port
8 Gb and
2-port 16 Gb
Fibre Channel
adapter
IBM Flex
System 4-port
16 Gb Fibre
Channel
adapter
IBM Flex
System 4-port
1 Gb Ethernet
and 4-port 10
Gb Ethernet
adapters
IBM Flex
System 8-port
10 Gb
converged
adapter
Un-P1-C19-L2-
T4*
Chassis I/O
bay 4
For more information about port mapping, see http://publib.boulder.ibm.com/infocenter/flexsys/information/
topic/com.ibm.acc.8721.doc/configuring_io_modules.html.
* Ports L2-T3 and L2-T4 require switches that have the capability of 56 internal ports.
Table 12. Location codes for IBM Flex System p460 Compute Node
Components Physical location code CRU LED
Un location codes are for enclosure and VPD locations.
Un = Utttt.mmm.sssssss
tttt = system machine type
mmm = system model number
sssssss = system serial number
DIMM 1 Un-P1-C1 Yes
DIMM 2 Un-P1-C2 Yes
DIMM 3 Un-P1-C3 Yes
DIMM 4 Un-P1-C4 Yes
DIMM 5 Un-P1-C5 Yes
DIMM 6 Un-P1-C6 Yes
DIMM 7 Un-P1-C7 Yes
DIMM 8 Un-P1-C8 Yes
DIMM 9 Un-P1-C9 Yes
DIMM 10 Un-P1-C10 Yes
DIMM 11 Un-P1-C11 Yes
DIMM 12 Un-P1-C12 Yes
DIMM 13 Un-P1-C13 Yes
DIMM 14 Un-P1-C14 Yes
DIMM 15 Un-P1-C15 Yes
DIMM 16 Un-P1-C16 Yes
DIMM 17 Un-P1-C17 Yes
DIMM 18 Un-P1-C18 Yes
DIMM 19 Un-P1-C19 Yes
DIMM 20 Un-P1-C20 Yes
DIMM 21 Un-P1-C21 Yes
DIMM 22 Un-P1-C22 Yes
DIMM 23 Un-P1-C23 Yes
112 Power Systems: IBM Flex System p260 and p460 Compute Nodes Installation and Service Guide
