Table 12. Location codes for IBM Flex System p460 Compute Node (continued)
Components Physical location code CRU LED
DIMM 24 Un-P1-C24 Yes
DIMM 25 Un-P1-C25 Yes
DIMM 26 Un-P1-C26 Yes
DIMM 27 Un-P1-C27 Yes
DIMM 28 Un-P1-C28 Yes
DIMM 29 Un-P1-C29 Yes
DIMM 30 Un-P1-C30 Yes
DIMM 31 Un-P1-C31 Yes
DIMM 32 Un-P1-C32 Yes
Solid-state drive interposer
(integrated in cover)
Un-P1-C33 Yes
SATA solid-state drive 1 Un-P1-C33-D1 Yes
SATA solid-state drive 2 Un-P1-C33-D2 Yes
Network adapter 1 Un-P1-C34 Yes
Network adapter 2 Un-P1-C35 Yes
Network adapter 3 Un-P1-C36 Yes
Network adapter 4 Un-P1-C37 Yes
Management card Un-P1-C38 Yes
2.5 in. SAS disk drive 1 Un-P1-D1 Yes
2.5 in. SAS disk drive 2 Un-P1-D2 Yes
Battery Un-P1-E1 Yes
USB port 1 (front panel) Un-P1-T1 No
Integrated SAS controller Un-P1-T2 No
Machine location code Utttt.mmm.sssssss No
Um codes are for firmware. The format is the same as for a Un location code.
Um = Utttt.mmm.sssssss
Firmware version Um-Y1
Table 13. Mapping network adapter ports to IBM Flex System Enterprise Chassis I/O bays for the IBM Flex System
p460 Compute Node
Port location
code
IBM Flex
System 2-port
QDR
InfiniBand
adapter
IBM Flex
System 2-port
10 Gb RoCE
adapter
IBM Flex
System 2-port
8 Gb and
2-port 16 Gb
Fibre Channel
adapter
IBM Flex
System 4-port
16 Gb Fibre
Channel
adapter
IBM Flex
System 4-port
1 Gb Ethernet
and 4-port 10
Gb Ethernet
adapters
IBM Flex
System 8-port
10 Gb
converged
adapter
Un-P1-C34-L1-
T1
Chassis I/O
bay 1
Chassis I/O
bay 1
Un-P1-C34-L1-
T2
Chassis I/O
bay 2
Chassis I/O
bay 2
Un-P1-C34-L1-
T3
Chassis I/O
bay 1
Chapter 8. Troubleshooting 113
