B
A
91357
(Left View)
8 Slot Riser Card
A
B
9135
7
91
357
A
B
(Left View)
(Right View)
5 Slot Riser Card
3 Slot Riser Card
Figure 2-8. Riser Cards
ARE THE VOLTAGES CORRECT?
Yes No
008
Replace the riser card. If the symptom remains, replace the system
board.
Diagnostic Information 2-77
