MAP 1700: Hard Disk Drive
Symptom Explanation
Conditions That Could Cause This
Symptom
You have entered this
MAP because you
received a 17XX error
message, or you suspect
a problem with the hard
disk drive.
The hard disk drive is failing.
The hard disk drive signal cable is
failing.
The hard disk drive jumper is in the
wrong position.
The system board is failing.
The power supply is failing.
The hard disk drive LED is failing.
Warning: Shipping and handling can result in permanent loss of all data
and formatting of the hard disk. In the event system software is not present
or has been removed from the hard disk, you must reinstall it. Refer to
“Software Installation Procedure” on page 4-48.
Hard Disk Drive Jumpers
The hard disk drives have jumper(s) that determine if the drive is the primary
(master) or secondary (slave) drive. If one hard disk drive is installed, it
must be set as the primary. If two hard disk drives are installed, one must
be set as the primary and one as the secondary drive. See “Hard Disk Drive
Jumper Settings” on page 4-2 and ensure the jumpers are in the correct
positions.
001
– Power off the system unit and wait 10 seconds.
– Ensure that all hard disk drive cables are properly connected.
– Remove any external devices except for the keyboard and mouse.
– Remove any adapter cards.
– Insert the Advanced Diagnostics diskette into drive A.
– Power on the system unit.
(Step 001 continues)
