2085—Indicator LED and Cable
Cover (2005).
Push in on the indicator LED and remove from the rear.
Disconnect the LED and cable from the system board.
See “Parts/Test Point Locations” on page 5-1 for LED and cable locations.
Indicator LEDs
4-44
