IBM PS/1 User Manual

Diagnostic Menus
Select an Option Menu
This menu appears first if the system options are correctly set.
@
SELECT AN OPTION
- SYSTEM CHECKOUT
1 - FORMAT DISKETTE
2 - COPY DISKETTE
3 - SETUP
9 - END DIAGNOSTICS
0 - SYSTEM CHECKOUT: Starts the system checkout procedure.
1 - FORMAT DISKETTE: Formats a scratch diskette for diagnostic use only.
2 - COPY DISKETTE: Copies the Advanced Diagnostics diskette to another
diskette.
3 - SETUP: Allows you to check or change the system configuration.
9 - END DIAGNOSTICS: Gives the option to restart the system.
Diskette Drive Menu
This menu allows you to test the diskette drives and the control logic on the
system board.
3-4

IBM PS/1 Specifications

General

Processor	Intel 80286 or 80386
Processor Speed	10 MHz (80286)
RAM	1 MB (expandable to 2 MB or more)
Storage	40 MB hard drive
Floppy Drive	3.5" 1.44 MB
Graphics	VGA
Ports	Serial, Parallel, Mouse
