6. If no errors occurred, the Log Utilities menu appears. If errors are dis-
played, go to “MAP 0010: Start” on page 2-3.
Setup Program
The Setup program allows the user to view or change the current system
configuration. The system configuration can be set through manual
selections or done automatically. In automatic configuration, the system
changes the configuration to what it determines is installed.
Set Configuration Menu
This menu allows you to change the current systems configuration:
1. From the SELECT AN OPTION menu, select 3 (SETUP).
2. Use the cursor up/down keys to select the configuration option.
3. Use the cursor right/left keys to change the configuration options.
4. Press Esc to save the change to the configuration.
Display Self Test
Be sure the display has been turned on for approximately 5 minutes before
you start the display self test. Run the test as follows:
1. Power off the system unit and display.
2. Disconnect the display signal cable from the system unit.
3. Power on the display.
4. Turn the brightness and contrast controls to their maximum positions.
5. The display screen should get lighter (it should not stay completely
black). You may want to check the display in a dark or dimly lit room.
6. The display screen should show a power-off discharge (a flash of light)
when turned off.
Note: If you can see the flash of light in Step 6 but not the lighter screen of
Step 5, you may want to perform Step 5 again in a dark or dimly lit room.
Diagnostic Aids 3-11
