082
Replace the SIMM indicated by the error.
Note: SIMM bank 0 is connector J2 and SIMM bank 1 is con-
nector J1.
If the symptom remains, replace the system board.
083
– Go to Step 095 on page 2-53.
084
The error message displayed indicates the failing SIMM by position. Refer
to the “System Board Layout” charts on pages 5-2 through 5-13 and “SIMM
Identification” on page 1-20.
– Make a note of the error.
– Power off the system unit.
– Move the four SIMMs to bank 1.
– Power on the system unit.
– If you get a POST error, press Esc.
– Run the memory test.
DID YOU RECEIVE AN ERROR?
Yes No
085
DID YOUR SYSTEM BOARD CONTAIN EIGHT SIMMS?
Yes No
086
Run the system memory test several times to verify the failure
symptom no longer exists.
Note: You may have a failing system board SIMM socket.
Test this by returning the SIMMs to the original sockets
and running the memory test. If the symptom returns,
Diagnostic Information 2-51
