IBM System x3200

System-board optional-devices connectors
The following illustration shows the system-board connectors for user-installable
optional devices.
DIMM 4
DIMM 3
DIMM 2
DIMM 1
Slot 4, PCI 32-bit/33 MHz
Slot 5, PCI 32-bit/33 MHz
Slot 3, PCI 32-bit/33 MHz
Slot 2, PCI Express x8
Slot 1, PCI Express x1
Remote Supervisor Adapter II SlimLine
Chapter 1. Introduction 11
