Replaceable server components
Replaceable components are of three types:
v Tier 1 customer replaceable unit (CRU): Replacement of Tier 1 CRUs is your
responsibility. If IBM installs a Tier 1 CRU at your request, you will be charged for
the installation.
v Tier 2 customer replaceable unit: You may install a Tier 2 CRU yourself or
request IBM to install it, at no additional charge, under the type of warranty
service that is designated for your server.
v Field replaceable unit (FRU): FRUs must be installed only by trained service
technicians.
For
information about the terms of the warranty and getting service and assistance,
see the Warranty and Support Information document.
Table 3. Parts listing, Types 4362 and 4363
Index Description
CRU part
number
(Tier 1)
CRU part
number
(Tier 2)
FRU part
number
1 Chassis assembly 42C8916
2 Front-panel assembly 25R8865
3 Front USB connector assembly (cable) 26K6096
4 CD-ROM, Half-high (primary for models: 3Bx 3Dx 4Bx
4Dx 5Bx 5Dx 5Fx 6Bx 6Dx)
39M0135
4 DVD/CD-RW (alternate for models: 3Bx 3Dx 4Bx 4Dx 5Bx
5Dx 5Fx 6Bx 6Dx)
26K5429
4 CD-RW drive, 48X (alternate for models: 32x, 34x, 42x,
44x, 52x, 54x, 56x, 62x, 64x )
39M3509
4 CD-RW drive, 48X (primary for models: 32x, 34x, 42x,
44x, 52x, 54x, 56x, 62x, 64x )
39M3511
4 CD-ROM drive, 48x (optional) 39M3517
4 Multiburner 39M3519
4 DVD-ROM drive, 16/48 (optional) 39M3515
4 DVD-RAM drive, Rambo 8 (optional) 42C0951
5 Diskette Drive, 1.44 MB (optional internal) 33P3343
6 Bezel, diskette drive 25R8857
7 Bezel, upper 42C8912
8 Bezel, lower 42C8913
9 Hard disk drive, SATA, 80 GB, fixed/simple-swap, with tray 39M4503
9 Hard disk drive, SATA, 160 GB, fixed/simple-swap, with
tray (optional)
39M4507
9 Hard disk drive, SATA, 250 GB, fixed/simple-swap, with
tray (optional)
39M4511
9 Hard disk drive, SAS, 36GB, 10K, hot-swap, with tray
(optional)
39R7364
9 Hard disk drive, SAS, 73 GB, 10 K, hot-swap, with tray
(optional)
39R7348
9 Hard disk drive, SAS, 146 GB, 10 K, hot-swap, with tray
(optional)
26K5713
68 System x3200 Types 4362 and 4363: Problem Determination and Service Guide
