IBM TS4500 User Manual

Power cords and receptacles
Refer to tables that list the feature codes for each type of required power cord for
your TS4500 tape library.
Power cords
Each frame receives single-phase (200–240 V ac) power on its own power cord
from a customer-supplied outlet. Refer to Figure 26 on page 96 and match the
number that is beside each receptacle to the receptacle number listed in the table.
Table 39. Specifications for power cords used with the TS4500 tape library xx5 frame models
Length and type of power cord
Part number
and feature
code
1
Type of service receptacle
Dual 4.3 m (14 ft.) watertight, international 250
V ac, 16 A single phase. This power cord is for
countries other than the United States and
Canada (IEC-309)
45E2699 / 9970
IEC-309 2P +GND 16 A
Uses receptacle #2
Dual 4.3 m (14 ft.) watertight, 250 V ac, 20 A
single phase. This power cord is for the United
States and Canada (IEC-309).
23R9540 / 9970
Hubbell HBL320R6W, IEC-309 2P +GND 20 A
Uses receptacle #2
Dual 4.3 m (14 ft.) non-watertight, twistlock 250
V ac, 15 A. This power cord is for the United
States and Canada.
39M5114 / 9972
NEMA L6-15R
Uses receptacle #1
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 10
A, IRAM 2073. This power cord is for
Argentina.
39M5066 / 9976 Uses receptacle #3
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 15
A, Earth Pin InMetro NBR 14136. This power
cord is for Brazil.
39M5238 / 9977 Uses receptacle #4
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 10
A, AS/NZS 3112/2000. This power cord is for
Australia and New Zealand.
39M5100 / 9978 Uses receptacle #3
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 15
A, JIS C8303, C8306. This power cord is for
Japan.
39M5184 / 9979 Uses receptacle #5
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 10
A, GB 2099.1, 1002. This power cord is for
China.
39M5204 / 9980 Uses receptacle #3
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 15
A, with earth pin KS C8305, K60884-1. This
power cord is for Korea.
39M5217 / 9981 Uses receptacle #6
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 10
A, CNS 10917-3. This power cord is for Taiwan.
39M5252 / 9982 Uses receptacle #5
Dual 4.3 m (14 ft.) non-watertight, 250 V ac, 16
A, SANS 164-1. This power cord is for South
Africa.
39M5142 / 9983 Uses receptacle #7
Dual 4.3 m (14 ft.) 250 V ac, 15A, single phase
power cord, non-watertight twistlock 20A
receptacles. This power cord is for US and
Canada.
23R9760 / 9984
NEMA L6-20R
Uses receptacle #8
94 IBM TS4500: Introduction and Planning Guide
