IBM TS4500 - Location of I;O Stations and Display Panel on an Lx5 Frame

Table 6. I/O stations and display panel
# Component # Component
▌1▐ I/O stations ▌6▐ I/O capacity indicator
▌2▐ Display panel ▌7▐ Lock status indicator
▌3▐ Power indicator (green) ▌8▐ Pause indicator (white)
▌4▐ Library beacon (blue) ▌9▐ Eject button
▌5▐ Warning indicator (yellow)
Cartridge magazine
The cartridge magazine is used to load and unload one or more tape cartridges
independent of the TS4500 tape library.
Figure 7. Location of I/O stations and display panel on an Lx5 frame
