PANEL DESCRIPTION
2-4
VIBRATION ICON
Displayed when the Vibration function is ON.
VOX ICON
Displayed when the VOX function is ON.
Bluetooth
®
ICON
• Displayed when Bluetooth
®
is activated.
• Lights Blue when a Bluetooth
®
device is connected.
• Does not light when no Bluetooth
®
device is
connected.
microSD ICON
Displayed when the microSD card is inserted into the
card slot.
L “ ”
is displayed when the microSD card has not
been formatted.
USB ICON
Displayed when a USB device is connected.
D Text Area
Displays the selected Zone number, Channel number,
and Channel name, if set.
D Key Display Area
Displays the names of the function assigned to [P1]
and [P2].
Function display (for the Portable type transceiver)
NOTE: The screen capture is an example. The
displayed position of each icon may differ, depending
on the function being used.
Icon Area
Text Area
Key Display
Area
Icons (Continued)
