Icom F6400DS 11 - D Mobile Type

2
PANEL DESCRIPTION
2-12
[OK]
[Emer]
[Up]/[Down]
[Right]/[Left]
[Back]
[P1] [P2]
F1 F2 F3
[Emer][Up]
[Down]
[F1] [F2] [F3]
z LCD type
z Segment type
Assignable keys, keypads, and switch (Continued)
D Mobile type
Dealers can assign the Software key functions to the
following keys and keypads.
LCD type:
[P1], [P2], [Up], [Down], [Left], [Right], [OK], [Back],
and [Emer]
Segment type:
[Up], [Down], [F1], [F2], [F3], and [Emer]
Optional HM-218 hand microphone:
[P1], [P2], [Up], [Down], [Left], [Right], [OK], [Back],
[Emer], Keypad 0~9, M, and #
z HM-218
[P1]
[P2]
[Back]
Ten-Key
Pad
[Emer]
[F2]
[F3]
[F1]
[Up]/[Down]
[Right]/[Left]
[OK]
