Icom F6400DS 11 - D Belt Clip (Portable)

1
ACCESSORIES
1-4
Accessory attachments (Continued)
D Belt clip (Portable)
To attach:
1. Remove the battery pack from the transceiver, if it
is attached.
2. Slide the belt clip in the direction of the arrow until
the belt clip is locked and makes a ‘click’ sound.
Belt clip
q
w
BE CAREFUL! Don’t break your ngernail.
To detach:
Lift the tab up (q), and slide the belt clip in the
direction of the arrow (w).
