PANEL DESCRIPTION
r MONITOR/LOW POWER MENU [MONI(LOW)]
➥Push to toggle the monitor function ON and OFF. (p. 24)
➥Push for 2 sec. to change the output power selection. (p.
25)
•Low (LO), mid-low (MID-LO), mid-high (MID-HI) and high (HI)
powers are available.
t MAIN BAND/MEMORY EDIT MENU [MAIN(EDIT)]
➥Push to select the main band. (p. 18)
➥Push for 2 sec. to enter the edit screen. (pgs. 29, 30, 37,
46, 51)
y TONE/DUPLEX MENU [TON(DUP)]
➥Push to activate the following functions in order.
•Subaudible tone encoder—“T” appears. (p. 26)
•Pocket beep—“T SQLì” appears. (p. 52)
•Tone squelch—“T SQL” appears. (p. 50)
•No tone operation—no indicator appears.
➥Push for 2 sec. to select semi-duplex or simplex opera-
tion. (p. 26)
•“DUP–” appears during minus duplex operation, “DUP” ap-
pears during plus duplex operation and no indicator appears
during simplex operation.
u SELECT MEMORY WRITE/MEMORY WRITE MENU
[S.MW(MW)]
➥Push to select the desired memory channel number to
be programmed. (p. 32)
➥Push for 2 sec. to program a memory channel or call
channel while in VFO mode. (p. 32)
➥Push for 2 sec. to transfer a memory channel, call chan-
nel or scratch pad memory contents into the VFO when
not in VFO mode. (p. 33)
i DTMF MENU [DTMF]
➥Push to toggle the DTMF memory ON and OFF. (p. 55)
➥Push for 2 sec. to enter the DTMF memory screen. (p.
54)
o DISPLAY/SET MODE MENU [DISP(SET)]
➥Push to enter the display set mode screen. (p. 68)
➥Push for 2 sec. to enter the set mode screen.
