OTHER FUNCTIONS
■ HM-97/118 [UP]/[DN] keys
Switches on the transceiver’s front panel can be assigned to
the HM-97/118 [UP] and [DN] keys. The following can be as-
signed:
V/U MAIN : [MAIN(SCP)] V/U V/MHz : [V/M
H
(TS)]
V/U M/C : [M/C(SCN)] V/U MONI : [MONI(LOW)]
V/U EDIT : [MAIN(EDIT)] V/U TONE : [TON(DUP)]
V/U MW : [S.MW(MW)] DTMF : [DTMF]
DISP : [DISP(SET)] Up : Microphone’s up
Dn : Microphone’s down
q Push [(DISP)SET] for 2 sec. to enter set mode.
•Push [CHG/L] if [(DISP)SET] is not displayed.
w Push [Y] or [Z] to select the ‘HM-118 Up’ or ‘Dn’ item.
•Left-hand tuning dial can also
select the item.
e Rotate the right-hand tuning
dial to select the desired
function.
r Push [ï] to exit set mode.
q Push [F SET] to enter set mode.
w Push [F SET] or [G ENT] to select the ‘HM-118
Up’ or ‘Dn’ item.
e Push [Y] or [Z] to select the desired function.
r Push [E CLR] to exit set mode.
[UP] or [DN] key assignment is available for the micro-
phones which have [UP]/[DN] switches except the HM-98.
■ Display contrast
The contrast of the LCD can be adjusted from 0% to 100% in
3 or 4% steps. Adjust contrast to suit lighting conditions and
personal preferences.
q Push [DISP] to enter display set mode.
•Push [CHG/L] if [DISP] is not displayed.
w Push [Y] to select the ‘Contrast’ item.
•Left-hand tuning dial can also select the item.
e Rotate the right-hand tuning dial to select the desired con-
trast.
r Push [ï] to exit display set mode.
