■ Setting a tuning step
Tuning steps can be selected for each band. This transceiver
has 8 tuning steps as follows:
•5 kHz •10 kHz •12.5 kHz •15 kHz •20 kHz
•25 kHz •30 kHz •50 kHz
q Select VFO mode with the desired band’s [V/M
H
].
•Push [CHG/L] if [V/M
H
] is not displayed.
w Push [(V/M
H
)TS] for 2 sec. to enter tuning step screen.
e Rotate desired band’s [DIAL] to select the desired tuning
step.
•Pushing [5], [20] or [25] also selects 5, 20 or 25 kHz tuning step.
r Push [í] to return to normal operation.
21
4
FREQUENCY SETTING
MAIN
43
3.000
14
5.000
12
í
5
20
25
SCP
MAIN
TS
V/M
H
SCN
M/C
LOW
MONI
TS = 5.0kTS = 5.0k
Return to previous menu
Shows 5 kHz tuning step is selected.
Select 5 kHz tuning step
Select 20 kHz tuning step
Select 25 kHz tuning step
•Cloning mode information
The information in the transceiver, such as memory chan-
nels, memory names, etc. can be programmed using a PC.
The transceiver displays the following information when the
transceiver enters cloning mode for programming.
In the cloning mode, the [POWER] switch does not func-
tion. Push the [UP]/[DN] or [Y]/[Z] on the microphone to
return to the normal operating condition.
Push mic UP/DN to EXIT.
CLONE
