■ Common settings
There are 3 setting menus available.
Common : Commonly set items such as operation
beeps, sub band mute, sub band beep, RF
attenuator, name display, TOT, auto repeater,
auto power-off, cooling fan setting, packet
data speed, squelch delay, VHF/UHF scan re-
sume timer and RF output power settings.
Display : Sets LCD contrast and brightness.
Select display type. Enter ‘Opening Title’ and
clone ‘Comment.’
MIC Option : Switches on the transceiver’s front panel can
be assigned to the microphone’s [F-1]/[F-2]
for the HM-98 and [UP]/[DN] for the HM-97
and HM-118/T/TA.
■ Exiting cloning mode
➥After cloning is finished, push the [UP]/[DN] or [Y]/[Z] on
the microphone to exit the cloning mode and to return to
normal operating condition.
•The [POWER] switch does not function in the cloning mode.
DO NOT disconnect the controller cable while in the
cloning mode.The transceiver remains in the cloning mode
and continues in power ON condition.
79
16
CS-2800 CLONING SOFTWARE
