Icom IC-7610

8
SET MODE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
8-3
Beep Sound (MAIN) (Default: 1000Hz)
Beep Sound (SUB) (Default: 1000Hz)
Set the audio frequency for beeps.
RF/SQL Control (Default: RF+SQL)
Set the
AF RF/SQL
(outer) control operation.
MENU
» SET > Function > TX Delay
HF (Default: OFF)
50M (Default: OFF)
Sets the TX delay time on the HF or 50 MHz band.
L If an external equipment’s rise time is slower than that
of the IC-7610, a reected wave is produced and it may
damage the IC-7610 or the external device. To prevent
this, set the appropriate delay time so that no reected
wave, or timing damage occurs.
LSelect “OFF” for no rise speed.
MENU
» SET > Function > Tuner
PTT Start (Default: OFF)
Turns the PTT Start Tuning function ON or OFF.
This function starts tuning when [PTT] is pushed,
if the operating frequency is shifted while the antenna
tuner is ON.
<<Preset Memory Clear>>
Clears all of the internal antenna tuner’s entered
memory frequencies.
MENU
» SET > Function
Transverter Function (Default: Auto)
Selects whether to turn ON the transverter function
or to automatically turn it ON when 2 to 13.8 V DC is
applied to pin 6 of [ACC 2].
Transverter Offset (Default: 16.000 MHz)
Sets the offset frequency for transverter operation.
RTTY Mark Frequency (Default: 2125)
Selects the RTTY mark frequency.
L When the internal RTTY decoder is used, 2125 Hz
is automatically selected.
RTTY Shift Width (Default: 170)
Selects the RTTY shift width.
L When the internal RTTY decoder is used, 170 Hz is
automatically selected.
RTTY Keying Polarity (Default: Normal)
Selects the RTTY keying polarity.
PSK Tone Frequency (Default: 1500)
Selects the PSK tone frequency for PSK reception.
MENU
» SET > Function > SPEECH
SPEECH Language (Default: English)
Selects the speech language.
SPEECH Speed (Default: Fast)
Selects the speech speed.
S-Level SPEECH (Default: ON)
Turns the S-meter level announcement ON or OFF.
MODE SPEECH (Default: OFF)
Turns the operating mode announcement ON or OFF.
SPEECH Level (Default: 50%)
Sets the Voice Synthesizer audio output level.
MENU
» SET > Function
Time-Out Timer (CI-V) (Default: OFF)
Sets the Time-out Timer for CI-V operation.
This setting is valid only transmitting initiated by a
CI-V command or pushing
TRANSMIT
.
LSelect “OFF” for no time limit.
Quick Dualwatch (Default: ON)
Turns the Quick Dualwatch function ON or OFF by
holding down
DUAL-W
for 1 second.
MENU
» SET > Function > SPLIT
Quick SPLIT (Default: ON)
Turns the Quick Split function ON or OFF by holding
down
SPLIT
for 1 second.
FM SPLIT Offset (HF) (Default: –0.100 MHz)
FM SPLIT Offset (50M) (Default: –0.500 MHz)
Sets the frequency offset for the Split function in the
FM mode on the HF or 50 MHz band.
SPLIT LOCK (Default: OFF)
Turns the Split Lock function ON or OFF.
SEND
Po
Rx
Tx
0 10
Delay time (ms)
