Icom IC-80AD - Display Set Mode Items (DISP)

129
12
MENU SCREEN OPERATION
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
 Display set mode items (DISP)
D Display backlighting (LIGHT)
The transceiver has display backlighting with a 5 sec. timer
for night time operation. The display backlighting can be
turned ON continuously or turned OFF, if desired.
• OFF : The backlight is turned OFF.
• ON : The backlight continuously lights ON.
• AUTO1 : Lights when an operation is performed, goes
out after 5 sec. (default)
• AUTO2 : Lights when an operation is performed, goes
out after 5 sec with a battery pack or battery
case operation, or stays ON when using the ex-
ternal power supply (more than 10 V DC).
D Busy LED (BUSY)
The TX/RX indicator lights green while receiving a signal or
when the squelch is open. This indication can be turned OFF
to conserve the battery power, if desired.
• OFF : The indicator does not function even if a signal is
received.
• ON : The indicator lights green while receiving a signal
or when the squelch is open.
(default)
D LCD contrast (CONT)
The contrast of the LCD can be selected from 4 levels.
• 1
(Low contrast) to 4 (High contrast) (default: 3)
High contrast (4)
Default (3)
