Icom IC-M412 - 12 Template

New2001
57
12
TEMPLATE
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Cut here
Unit: mm (inch)
164 (6
15
⁄
32
)
78 (3
1
⁄16)
149 (5
7
⁄8)
61.6 (2
7
⁄
16
)
R8 (Max.)
NOTE: The solid line is the line to use when cutting into the dash/helm.
The dotted line shows the outline of the IC-M412’s front panel once the radio is fitted into the hole.
DO NOT follow the dotted line when making the hole in your dash/helm.
