OTHER FUNCTIONS
RX Speaker function ■
The RX Speaker function enables you to hear the received
audio on the deck or bridge through a PA speaker.
Connect a PA speaker as described on page 83.
Push q
[RX ] to enter the RX Speaker mode.
 •TheRXSpeakervolumeleveladjustmentscreenisdisplayed.
Rotate Dial or push [ w Y]/[Z]/[Ω]/[≈] to adjust the RX Speak-
er volume level, and then push [ENT].
 •“RX ” appears.
e To return to normal operating mode, push [RX ].
 •“RX ” disappears.
To adjust the audio output level in the RX Speaker mode,
hold down
[RX ] for 1 second to display the RX Speaker
volume level adjustment screen, and then rotate Dial. After
adjusting, push [ENT] to set it.
PA (Public Address) function ■
The transceiver has a PA function to make announcements
through a PA speaker.
Connect a PA speaker rated at
more than 10 W at 10% distor-
tion with a 4 ˘ load,
as described on page 83.
•TransmittingisdisabledwhileinthePAmode.
Push [PA] to enter the Public Address mode. q
Hold down [PTT] and speak at a normal voice level. w
 •Whileholdingdown[PTT],thescreenbelowisdisplayed.
 •ToadjustthePAvolumelevel,rotateDial.
Push [EXIT] to return to normal operating screen. e
While in the PA mode, the transmit and receive functions
are disabled. When the transceiver is transmitting, the PA
function is disabled.
Appears
