MENU SCREEN OPERATION
New2001
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
Menu screen items ■
The Menu screen contains the following items.
DSC Calls D
Item Ref. Item Ref.
•IndividualCall p. 28 •
Transmitted Call Log p. 65
•IndividualACK*
1
p. 30 •PositionRequestCall *
2
p. 35
•GroupCall p. 32
• Position Report Call*
2
p. 37
•AllShipsCall p. 34 •PollingRequestCall*
2
p. 39
•DistressCall p. 25 •TestCall p. 41
•ReceivedCallLog p. 63 •TestACK*
1
p. 44
DSC Settings D
Item Ref. Item Ref.
•PositionInput*
3
p. 23 •CH16Switch p. 67
•IndividualID p. 20 •DSCDataOutput p. 68
•GroupID p. 21 •Alarm p. 68
•IndividualACK p. 66 •CH70SQLLevel p. 69
•PositionACK p. 66 •DSCLoopTest p. 69
•TestACK p. 66
*
1
Appears only after receiving a corresponding call.
*
2
Only U.S.A. and Australian version transceivers.
*
3
Appears only when no GPS information is received.
*
4
Appears only when the optional HM-195 is connected.
*
5
Appears only when a GPS receiver compatible with NMEA0183
ver. 2.0 or 3.01 is connected.
Radio Settings D
Item Ref. Item Ref.
•ScanType p. 77 •ChannelGroup p. 77
•ScanTimer p. 77 •WXAlert*
2
p. 78
•Dual/Tri-Watch p. 77
Configuration D
Item Ref. Item Ref.
•Backlight p. 78 •NoiseCancel p. 80
•DisplayContrast p. 78 •InactivityTimer p. 81
•KeyBeep p. 78 •RemoteID p. 81
•KeyAssignment p. 79 •COMMANDMICSP*
4
p. 82
•UTCOffset p. 80
MMSI/GPS Information D
The transceiver shows the programmed MMSI code and GPS
information*
5
.
If the code is not programmed, “NO DSC MMSI” is displayed.
