Icom IC-R6 User Manual

49
9
SET MODE
New2001
D Expand set mode (EXPAND)
Turn the Expand set mode ON or OFF. (default: OFF)
• OFF : Displays only the regular Set mode.
• ON : Displays the regular set mode and the Expand
set mode.
D Key lock effect (LOCK)
Even while the key lock function is ON, the volume control,
squelch adjustment and monitor key ([SQL]) is still usable.
Usable keys can be set to one of four groups.
[ ] and [FUNC]+[ ](BAND) are also usable during the
locked state. However, these switches are not effected by
this setting. (default: NORMAL)
• NORMAL : Volume control, squelch adjustment and
monitor key are accessible.
• NO SQL : The squelch adjustment and monitor key are
accessible. (The function of [SQL] is not locked.)*
• NO VOL : Volume control is accessible. (The function of
volume control is not locked.)*
• ALL : No key function is usable, except [ ] and
[FUNC]+[ ](BAND).
*“NO” indicates the function is not locked.
D Dial speed acceleration (SPEED)
The dial speed acceleration automatically speeds up the
tuning dial speed, when rotating [DIAL] rapidly. (default: ON)
• OFF : The dial speed acceleration is turned OFF.
• ON : The dial speed acceleration is tuned ON.
D Monitor switch action (MONI)
The monitor switch, [SQL], can be set as a ‘sticky’ switch.
When set to the sticky condition, each push of [SQL] toggles
the monitor function ON or OFF. (default: PUSH)
• PUSH : Hold down [SQL] to monitor the frequency.
• HOLD : Push [SQL] momentarily to monitor the fre-
quency and push momentarily again to cancel it .

Icom IC-R6 Specifications

General

Product color	Black
Channels quantity	1550 channels
Supported radio bands	AM, FM
Battery type	AA
Number of batteries supported	2
Impedance	16 Ω
Frequency range	0.1 - 1309.995 MHz
Product type	Portable CB radio
Housing material	-

Weight and Dimensions

Depth	29.8 mm
Width	58 mm
Height	86 mm
Weight	200 g
