Icom IC-V86 User Manual

5
MEMORY/CALL OPERATION
5-4
Contents of programmed memories can be cleared
(deleted).
1. Push [VFO/MR/CALL] several times to select the
memory or Call channel mode.
• For only the USA version:
Select any mode other than the weather
channel mode.
2. Push [FUNC], and then push [VFO/MR/CALL].
• “X” and “--” blink.
3. Push [Y] or [Z] to select the channel to be
cleared.
• Memory channels not yet programmed are
blank.
4. Perform the following operation within 1.5
seconds, otherwise the transceiver returns to the
memory mode without clearing memory.
1 Push [FUNC], and then momentarily push
[VFO/MR/CALL].
2 Push [FUNC], and then hold down [VFO/MR/
CALL] for 1 second
• 3 beeps sound, and then the memory
channel is cleared.
5. Push [VFO/MR/CALL] to return to the previous
mode.
BE CAREFUL! The contents of cleared memories
CANNOT be recalled.
Example: Clearing memory channel 11.
Push and then push .
Push or to select channel 11.
Perform the following operation with in 1.5 seconds
Push , and then push ,
and push , and then hold down for 1 second again.
Push to return to the previous mode.
Clearing memory contents

Icom IC-V86 Specifications

General

Frequency Range	136-174 MHz
Output Power	7 W
Waterproof Rating	IP54
Mode	FM
Channel Spacing	12.5/25 kHz
Antenna Impedance	50Ω
Modulation System	Variable reactance frequency modulation
Spurious Response	70 dB
Maximum Frequency Deviation	±5 kHz
Spurious Emissions	-60 dB
Audio Distortion	Less than 10% (at rated audio output)
Battery Life	Up to 19 hours (BP-298)
Dimensions	58 x 112 x 30 mm; 2.3 x 4.4 x 1.2 in (W x H x D, Projections not included)
