Icom IC-V86 User Manual

9
SET MODES
9-4
VOX time-out timer
Set the VOX time-out timer to between 1, 2, 3, 4, 5,
10, and 15 minutes, to prevent accidental prolonged
transmission by the VOX function. To turn OFF the
function, select “Vto.OF.” (Default: 3)
The “VOX time-out timer” item in the Set mode
The VOX time-out timer
is set to 3 minutes.
VOX time-out timer
is set to 15 minutes
(maximum).
The VOX time-out timer must be set shorter than the
Time-out timer, otherwise the VOX time-out timer will
not function.
DTMF TX key
Selects the method to transmit a DTMF code
sequence. (Default: dmt.k)
• dmt.k: Transmits the appropriate DTMF code
assigned to the key. (p. 8-3)
• dmt.m: Transmits the programmed DTMF code
sequence in the DTMF memory channel
assigned to the key.
• dmt.t:
No DTMF code can be transmitted. (p. 8-3)
However, while holding down [PTT],
pushing either [Y] or [Z] transmits the
1750 Hz tone burst.
Mode
Set both the transmission and reception passband
width to wide or narrow. (Default: W/n. W)
Wide (FM mode) Narrow (FM-N mode)
Set mode items

Icom IC-V86 Specifications

General

Frequency Range	136-174 MHz
Output Power	7 W
Waterproof Rating	IP54
Mode	FM
Channel Spacing	12.5/25 kHz
Antenna Impedance	50Ω
Modulation System	Variable reactance frequency modulation
Spurious Response	70 dB
Maximum Frequency Deviation	±5 kHz
Spurious Emissions	-60 dB
Audio Distortion	Less than 10% (at rated audio output)
Battery Life	Up to 19 hours (BP-298)
Dimensions	58 x 112 x 30 mm; 2.3 x 4.4 x 1.2 in (W x H x D, Projections not included)
