Icom IC-V86 User Manual

1
ACCESSORIES
1-2
Supplied Accessories
Battery pack*
Jack cover
(with screws)
Battery charger*
Belt clip
Power adapter*
Antenna*
* Not supplied, or the shape is different, depending on
the transceiver version.
Antenna
Insert the antenna into the antenna connector and
twist the antenna base to lock it in place.
CAUTION:
• NEVER HOLD just the antenna when carrying the
transceiver.
• DO NOT transmit without an antenna.
Belt clip
To attach the belt clip:
z Slide the belt clip in the direction of the arrow until
the belt clip locks in place, and makes a ‘click’
sound.
Belt clip
Battery pack/case
To detach the belt clip:
1. Remove the battery pack or case from the
transceiver, if it is attached.
2. Lift the tab up (1), and slide the belt clip in the
direction of the arrow (2).

-

Icom IC-V86 Specifications

General

Frequency Range	136-174 MHz
Output Power	7 W
Waterproof Rating	IP54
Mode	FM
Channel Spacing	12.5/25 kHz
Antenna Impedance	50Ω
Modulation System	Variable reactance frequency modulation
Spurious Response	70 dB
Maximum Frequency Deviation	±5 kHz
Spurious Emissions	-60 dB
Audio Distortion	Less than 10% (at rated audio output)
Battery Life	Up to 19 hours (BP-298)
Dimensions	58 x 112 x 30 mm; 2.3 x 4.4 x 1.2 in (W x H x D, Projections not included)
