ACCESSORIES
1-3
Battery pack or case
CAUTION: When the battery case is attached, the
Battery Protection function must be turned OFF in
the Initial Set mode. (p. 9-7)
To attach the battery pack or case:
1. Insert the battery pack or case in the direction of
the arrow (1), then close.
2. Hook the latch until it makes a ‘click’ sound (2).
-
Battery pack/case
Latch
To remove the battery pack or case:
R WARNING! The latch is tightly locked, so use
caution when releasing it. DO NOT use your
ngernail.Usetheedgeofacoinorscrewdrivertip
to carefully release it.
z Unhook the latch (1), and then lift up the battery
pack or case in the direction of the arrow (2).
CAUTION: NEVER remove or attach the battery
pack or case when the transceiver is wet or soiled.
This may result in water or dust getting into the
transceiver or the battery pack or case, and may
result in them being damaged.
NOTE: Keep battery terminals clean. It’s a good idea
to occasionally clean them.
Jack cover
Attach the jack cover when optional equipment is not
used.
To attach the jack cover
1. Attach the jack cover
to the [SP MIC] jack
(1).
2. Insert and tighten the
screws (2).
To detach the jack cover
1. Remove the screws
with a phillips
screwdriver (1).
2. Detach the jack cover
to connect optional
equipment (2).
-
-
