Icom IC-V86 User Manual

2
BATTERY CHARGE
2-4
Optional battery case (BP-263)
When using the battery case (BP-263), install 6 × AA
(LR6) size alkaline batteries, as described below.
Remove the battery case, if it is attached. (p. 1-3)
Install 6 × AA (LR6) size alkaline batteries.
Install only alkaline batteries.
Be sure to observe the correct polarity.
Attach the battery case. (p. 1-3)
CAUTION:
• When installing batteries, make sure they are all
the same brand, type and capacity. Also, do not
mix new and old batteries together.
• Keep battery terminals clean. It’s a good idea to
occasionally clean them.
• Never incinerate used battery cells since the
internal battery gas may cause them to rupture.
• Never expose a detached battery case to water.
If the battery case gets wet, be sure to wipe it dry
before using it.
• Never use batteries whose insulated covering is
damaged.
BE CAREFUL! The negative
terminals of the battery case
protrude from the body, so
pay attention not to injure your
ngerswheninsertingthe
batteries.

Icom IC-V86 Specifications

General

Frequency Range	136-174 MHz
Output Power	7 W
Waterproof Rating	IP54
Mode	FM
Channel Spacing	12.5/25 kHz
Antenna Impedance	50Ω
Modulation System	Variable reactance frequency modulation
Spurious Response	70 dB
Maximum Frequency Deviation	±5 kHz
Spurious Emissions	-60 dB
Audio Distortion	Less than 10% (at rated audio output)
Battery Life	Up to 19 hours (BP-298)
Dimensions	58 x 112 x 30 mm; 2.3 x 4.4 x 1.2 in (W x H x D, Projections not included)
