PANEL DESCRIPTION
7
e LOW POWER INDICATORS (p. 17)
Appear when low output power is selected.
r S/RF INDICATORS (p. 17)
➥Show the relative signal strength while receiving.
➥Show the output power selection while transmitting.
t TONE INDICATORS (pgs. 19, 32)
“T” appears when the subaudible tone encoder is in use;
“TSQLS” appears during pocket beep operation and
“T SQL” appears when the tone squelch function is acti-
vated.
y DUPLEX INDICATORS (p. 19)
Appear when semi-duplex operation (repeater operation)
is in use.
•“–DUP” appears when minus duplex is selected; “DUP” only, ap-
pears when plus duplex is selected.
u SKIP INDICATORS
➥Appear when a selected memory channel is set as a
skip channel. (p. 30)
•Skip channels are not detected (ignored) during memory
scan.
➥Flash during full/programmed scan when the frequency
skip function is activated. (p. 31)
i ALPHANUMERIC READOUT
➥Shows the selected memory channel number in mem-
ory mode.
•Memory name can be selected instead of channel numbers.
(p. 24)
➥Shows guide (or description) when the [L/G] and desired
keys are pushed, or no key operation is performed for 5
sec. in set mode, during name programming, etc. (p. 34)
o LOCK INDICATOR (p. 15)
Indicates that the lock function is in use.
!0 QUICK GUIDE INDICATOR (p. 34)
Appears when the quick guide function is activated.
