Icom MR-1220 Series User Manual

Fixed ring range readout
Screen range readout
Trail indicator
Vector indicator
Rain control icon
SEA icon
Reference indicator
AIS icon*
2
Own track icon
Long pulse icon
North mark
Cross-line cursor
Fixed range rings
EBL/ VRM 1
readouts
Own ship
information*
3,
*
4
Cursor
information*
5,
*
6
Target Information box*
5,
*
6
EBL/ VRM 2
readouts
EBL 1
ARPA icon*
4,5
EBL 2
VRM 1
VRM 2
Own ship vector
indicator
Waypoint marker
Heading line
Echo Stretch icon
Zoom icon
IR icon
Alarm icons
Tuning mode
indicator
Mode indicator*
1
Heading indicator*
7,
*
8
Alarm zone
MR-1220 series
OPERATING GUIDE
■ Display information
*1 North-up and Course-up screens require a bearing input (NMEA, N+1 or AUX.)
*2 AIS data is required.
*3 Your position data is required.
*4 GPS data is required.
COG (Course Over Ground), SOG (Speed Over Ground)
*5 Bearing data and position data are required.
*6 R: Relative bearing, T: True bearing, M: Magnetic bearing
*7 T: True bearing, M: Magnetic bearing
*8 COG (Course Over Ground) is displayed when the “Bearing Input” item in the Initial menu is set to “GPS” or “GPS-L.”
When using COG instead of HDG (HeaDinG), the heading indicator may differ from the vessel’s actual bow direction.
Refer to the Instruction Manual for details about the ARPA, the AIS receiver, and DSC functions.
