25
5
AIS RECEIVER
AIS description
AIS operation
D Course and speed vectors
The vector indicates the target’s predicted, true or
relative course and speed.
• The vector time may change, depending on the
setting in the “Vector Time” item of the Target menu
(p. 39).
• The tip of the vector shows the target’s predicted
position after the time selected in the “Vector Time”
item of the Target menu (p.39).
Speed Over Ground (SOG) and
Course Over Ground (COG) vector
Rate of turn (ROT)
Heading line
LIf the heading data is not received,
The line indicates the vessel’s COG.
D Plots (AIS)
The plot displays the activated target, SAR, SART,
MOB, or EPIRB’s past positions as 5 dots, during
each specied tracking interval.
L The target track interval may change, depending on the
setting in the “Track Interval” item of the Target menu.
(p. 39)
Plots Status
Going straight
Turning right
Decelerating (dots are closer
together behind the target)
Accelerating (dots are father apart
behind the target)
D Displaying AIS target details
You can also display the more details on an AIS target
from a context menu.
1. Move the cursor onto an AIS target.
• The target is highlighted.
2. Hold down [ENTER]/[ ] for 1 second.
• The context menu is displayed.
3. Select “Display Details,” and then push [ENTER]/
[ ].
• The detailed AIS information is displayed in the
window.
L Push [CLEAR]/[ ] to close the window.
TIP: You can display the AIS details by moving the
cursor to in the Information box and pushing
[ENTER]/[ ].
D Received AIS list
The list of received AIS is in the AIS List menu.
The targets are displayed with their MMSI numbers, or
names of the ships, if entered.
[MENU]/[
] > AIS List
TIP: You can enter the selected target in the list by
holding down [ENTER]/[ ] for 1 second and select
“Add to Favorite”.
