Figure 10: Internal Connectors
Inputs 4 pin connector
FUNCTION
J4
Accessory
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J5
Tamp Home
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J6
Smart Sensor
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J12
Reserved
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J17
Low Label
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J22
Reserved
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
J23
Reserved
Pin 1: +24V Pin 2 & 3: Signal (NPN) Pin 4: 0V
Inputs 3 pin connector
FUNCTION
J1
Pressure 1
Pin 1: +5V Pin 2: Signal Pin 3: 0V
J2
Pressure 2
Pin 1: +5V Pin 2: Signal Pin 3: 0V
J3
Pressure 3
Pin 1: +5V Pin 2: Signal Pin 3: 0V
J32
Reserved
Pin 1: +5V Pin 2: Signal Pin 3: 0V
J33
Reserved
Pin 1: +5V Pin 2: Signal Pin 3: 0V
J34
Reserved
Pin 1: +5V Pin 2: Signal Pin 3: 0V
The internal connectors and signals are designed to work with ID Technology standard
accessories. Use of non-approved components may give unexpected results, may lead to
equipment damage and may void warranty.
