Model 252
Label Printer/Applicator
Operators/Technical Manual
16
Outputs 2 pin connector
FUNCTION
J7
Fan
Pin 1: +24V Pin 2: Signal (NPN)
J8
Air Assist Valve
Pin 1: +24V Pin 2: Signal (NPN)
J9
Tamp Valve
Pin 1: +24V Pin 2: Signal (NPN)
J10
Tampjet Valve
Pin 1: +24V Pin 2: Signal (NPN)
J11
Vacuum Valve
Pin 1: +24V Pin 2: Signal (NPN)
J14A
Rewind Motor RH
Pin 1: Signal (+24V) Pin 2: 0V
J14B
Rewind Motor LH
Pin 1: 0V Pin 2: Signal (+24V)
J20 Reserved
Pin 1: +24V Pin 2: Signal (NPN)
J21 Reserved
Pin 1: +24V Pin 2: Signal (NPN)
J24
Reserved
Pin 1: +24V Pin 2: Signal (NPN)
J25
Reserved
Pin 1: +24V Pin 2: Signal (NPN)
J26
Analog Output
Pin 1: +5V Pin 2: 0V
J27
Reserved
No Function
The internal connectors and signals are designed to work with ID Technology standard
accessories. Use of non-approved components may give unexpected results, may lead to
equipment damage and may void warranty.
