ID Technology 252 - Page 139

Model 252
Label Printer/Applicator
Operators/Technical Manual
23
1
1
2
2
3
3
4
4
A A
B B
C C
D D
SHEET 2 OF 2
DRAWN
CHECKED
QA
MFG
APPROVED
DWG NO
TITLE
SIZE
SCALE
REV
2051 FRANKLIN DR.
FORT WORTH, TX 76106
.00
02
.000
ANGLE
1

005
STANDARD
TOLERANCE
clari
10/4/2012
ID100021 / ID100022
ASSY,REWIND 252 14"
C
E
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
1 4
M3x10 SHCS
2 2 M4x12 PFHCS
3
4
M4x8 SHCS
4 1
M5x10 SHCS
5
3 M6x10 PPHS
6 2 M6x20 SHCS
7 1
M6x30 SHCS
8
1
M6x45 SHCS
9
1 M6x6 SSS CUP SS
10 1 Retaining Ring,Ext. 5101
Series
11 1
Shim,
.5"IDx.75"ODx.03"THK SS
12
4
Washer,Flat M4 SS
13
1
Washer,Flat M5 SS
14
3
Washer,Flat M6 SS
15 4
Washer,Lock Split M4 SS
16
1
Washer,Lock Split M5 SS
17
3
Washer,Lock Split M6 SS
18 3 60224 WASHER,DIRECTIONAL .8
OD X .25 ID
19 2 62027 PIN, SPRING ANCHOR
20 2 62030-08 ROLL,IDLER
PARTS LIST
ITEM
QTY
PART NUMBER
DESCRIPTION
21 2 62031 SHAFT,IDLER
22 2 62032
BUSHING,FLANGED 1/2"
BRONZE
23
1
62055 CLIP,REWIND
24
1
62058 BELT,V 60DEG.
25
1
7621 CLAMP,CABLE 0.125
26
1
ID100023 PLATE,REWIND MOUNTING
27
1
ID100024 COVER,REWIND
28
1
ID100025
ARM,DANCER REWIND
TENSION
29
1
ID100026 HUB,TENSIONER BEARING
30
1
ID100027 PIVOT,REWIND DANCER
31
1
ID100028
PULLEY,V-BELT
32
1
ID100029 SHAFT,REWIND
33
1
ID100030 SPACER,REWIND SHAFT
34
1
ID100031 SPINDLE,REWIND
35
1
ID100039 GEARMOTOR,24VDC
140RPM
36 2 ID100041 BEARING,BALL FLANGE
1/2x1-1/8x5/16x1.225x1/16
37
1
ID100042
DISK,REWIND 14"
38 2 ID100043 BEARING,BALL
1/2x1-1/8x5/16
39
1
ID100251
Spring,Extension
.437x.0475x3.0 ZP
